Dell Compatible QSFP-DD 400GBASE FR4 1271/1291/1311/1331nm 2km SMF Duplex LC DDM/DOM Optics Transceiver

Name: Dell Compatible QSFP-DD 400GBASE FR4 1271/1291/1311/1331nm 2km SMF Duplex LC DDM/DOM Optics Transceiver
Brand: INPHE.COM - Optics | Fiber | Networks
SKU: 709000301034
Price: 499 USD
Availability: InStock

#709000301034

US$499.00

INPHE: QDD-400G-FR4

Received successfully

Coupon Code

CONTINUE SHOPPING

Compatible Brands:

Cisco Juniper Arista NVIDIA (Mellanox) Nokia Huawei Dell HPE (Aruba) FS.COM Flexoptix Precision More +

Compatible Models:

QDD-400G-FR4 Customized

QTY:

Specifications

The Dell compatible QSFP-DD 400G-FR4 Optics is designed for short-distance single-mode connections in data centers and telecom.

Featuring a EML transmitter and a PIN receiver, and operating at a wavelength of CWDM4 (1271nm/1291nm/1311nm/1331nm), this Optics utilizes an Duplex LC connector to deliver 400G transmission and exceptional reliability over link distances of up to 2km (OS2 SMF). It is an ideal choice for short-distance, high-speed transmission applications within data centers and enterprise networks.

The INPHE 400G-FR4 uses Marvell 7nm DSP.

It supports both DDM/DOM (Digital Optical Monitoring)

Primary Application:
1. 400G Point-to-Point Connections

Vendor Name	INPHE	Part Number	QDD-400G-FR4
Form Factor	QSFP-DD	Max Data Rate	425Gbps
Wavelength	1310nm	Max Distance	2km
Connector	Duplex LC	Transmitter Type	EML
Cable Type	SMF	Receiver Type	PIN
Transmitter Power	-3.3 ~ +3.5dBm	Receiver Sensitivity	< -4.6dBm
Protocols	IEEE 802.3bs, QSFP-DD MSA	Operation Temperature	0 to 70°C (32 to 158°F)
DDM/DOM	Supported	Warranty	10 Years
