Huawei 02314LCB QSFP-100G-SWDM4 Compatible QSFP28 100GBASE SWDM4 850/880/910/940nm 100m MMF Duplex LC With Dual CDR DDM/DOM Optics Transceiver

Name: Huawei 02314LCB QSFP-100G-SWDM4 Compatible QSFP28 100GBASE SWDM4 850/880/910/940nm 100m MMF Duplex LC With Dual CDR DDM/DOM Optics Transceiver
Brand: INPHE.COM - DCI | HPC | Enterprise Network
SKU: 707000402056
Price: 139 USD
Availability: InStock

#707000402056

US$139.00

INPHE: 02314LCB

Received successfully

Coupon Code

CONTINUE SHOPPING

Compatible Brands:

Cisco Juniper Arista Huawei FS.COM Flexoptix Precision Coherent (Finisar) MikroTik Edge CorE UfiSpace More +

Compatible Models:

02314LCB

02311QUK Customized

QTY:

Specifications

Vendor Name	INPHE	Part Number	QSFP-100G-SWDM4
Form Factor	QSFP28	Max Data Rate	103.1Gbps
Wavelength	850/880/910/940nm	Max Distance	OM4 100m / OM3 70m
Connector	Duplex LC	Transmitter Type	VCSEL
Cable Type	MMF	Receiver Type	PIN
Transmitter Power	-7.5 ~ +4.0dBm	Receiver Sensitivity	< -8.5dBm
Protocols	100G Ethernet, MSA Compliant	Operation Temperature	0 to 70°C (32 to 158°F)
DDM/DOM	Supported	Warranty	3 Years
